Asus TUF Gaming F15 TUF507 RTX 4070 (2023) vs Lenovo Legion 5 15ARP8 RTX 4060 (2023)
What TUF Gaming F15 TUF507 RTX 4070 (2023) does better (13) and where Legion 5 15ARP8 RTX 4060 (2023) wins (12) — every spec side by side.
vs
8.2Graphics6.3
7.6Overall performance5.9
6.0Display8.7
2.8Memory & storage8.6
9.6Battery & portability6.6
5.2Features & cooling4.1
Dimensions
Size comparison
TUF Gaming F15 TUF507 RTX 4070 (2023)Legion 5 15ARP8 RTX 4060 (2023)
| TUF Gaming F15 TUF507 RTX 4070 (2023) | Legion 5 15ARP8 RTX 4060 (2023) | Difference | |
|---|---|---|---|
| Depth | 251 mm | 262.4 mm | −11.4 mm |
| Width | 354 mm | 358.8 mm | −4.8 mm |
| Thickness | 23 mm | 24.1 mm | −1.1 mm |
| Weight | 2.2 kg | 2.4 kg | −0.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is TUF Gaming F15 TUF507 RTX 4070 (2023) better than Legion 5 15ARP8 RTX 4060 (2023)?
- Thunderbolt or USB4Yes · Legion 5 15ARP8 RTX 4060 (2023): No
- Battery capacity90 Wh vs 80 Wh+12%
- GPU compute (FP32)21.8 TFLOPS vs 16 TFLOPS+36%
- 3DMark Steel Nomad Light14,045 vs 10,487+34%
- GPU shader cores4,608 vs 3,072+50%
- Weight2.2 kg vs 2.4 kg+9%
- CPU cores10 vs 8+25%
- RAM (base)16 GB vs 8 GB2×
- Dolby AtmosYes · Legion 5 15ARP8 RTX 4060 (2023): No
- SSD (base)1,000 GB vs 512 GB+95%
- Thickness23 mm vs 24.1 mm+5%
- Key travel1.7 mm vs 1.5 mm+13%
Why is Legion 5 15ARP8 RTX 4060 (2023) better than TUF Gaming F15 TUF507 RTX 4070 (2023)?
- RAM (up to)16 GB vs 64 GB4×
- SSD (up to)1,000 GB vs 4,096 GB4.1×
- Resolution classFull HD (1080p/1200p) vs QHD (1440p/1600p)
- Refresh rate144 Hz vs 165 Hz+15%
- Response time7 ms vs 3 ms2.3×
- Advanced OptimusNo · TUF Gaming F15 TUF507 RTX 4070 (2023): Yes
- HDRNo · TUF Gaming F15 TUF507 RTX 4070 (2023): Yes
- Max. supported RAM32 GB vs 64 GB2×
- HDMI 2.1No · TUF Gaming F15 TUF507 RTX 4070 (2023): Yes
- Brightness300 nits vs 350 nits+17%
- USB-A ports2 vs 3+50%
- Pixel density141 ppi vs 188 ppi+33%
Specifications
Side by side
| Graphics | ||
| Graphics card | GeForce RTX 4070 Laptop | GeForce RTX 4060 Laptop |
| GPU maker | NVIDIA | NVIDIA |
| GPU power (TGP) | 140 W | 140 W |
| Video memory | 8 GB | 8 GB |
| Video memory type | GDDR6 | GDDR6 |
| GPU shader cores | 4,608 | 3,072 |
| GPU compute (FP32) | 21.8 TFLOPS | 16 TFLOPS |
| 3DMark Steel Nomad Light | 14,045 | 10,487 |
| Processor | ||
| Processor | Core i7-13620H | Ryzen 7 7735HS |
| CPU maker | Intel | AMD |
| CPU cores | 10 | 8 |
| CPU threads | — | 16 |
| Max CPU clock | 4.9 GHz | 4.8 GHz |
| Processor options | Core i7-12700H, Core i7-13620H, Core i7-13700H, Core i9-13900H | Ryzen 7 7735HS |
| Geekbench 6 multi-core | — | 10,140 |
| Geekbench 6 single-core | — | 2,153 |
| Cinebench 2024 multi-core | — | 738 |
| Display | ||
| Screen size | 15.6″ | 15.6″ |
| Resolution | 1920 × 1080 | 2560 × 1440 |
| Resolution class | Full HD (1080p/1200p) | QHD (1440p/1600p) |
| Refresh rate | 144 Hz | 165 Hz |
| Panel type | IPS | IPS |
| Brightness | 300 nits | 350 nits |
| sRGB coverage | 100% | 100% |
| Response time | 7 ms | 3 ms |
| Pixel density | 141 ppi | 188 ppi |
| Aspect ratio | 16:9 | 16:9 |
| G-Sync / FreeSync | Yes | Yes |
| Advanced Optimus | No | Yes |
| MUX switch | Yes | Yes |
| HDR | No | Yes |
| Touchscreen | No | No |
| Memory & storage | ||
| RAM (up to) | 16 GB | 64 GB |
| RAM (base) | 16 GB | 8 GB |
| RAM type | DDR5 | DDR5 |
| RAM speed | 4,800 MHz | 4,800 MHz |
| Max. supported RAM | 32 GB | 64 GB |
| RAM slots | 2 | 2 |
| Upgradable RAM | Yes | Yes |
| SSD (up to) | 1,000 GB | 4,096 GB |
| SSD (base) | 1,000 GB | 512 GB |
| M.2 SSD slots | 2 | 2 |
| SSD interface | PCIe 4.0 x4 | PCIe 4.0 x4 |
| Battery & power | ||
| Battery capacity | 90 Wh | 80 Wh |
| Power adapter | 240 W | 230 W |
| USB-C charging (Power Delivery) | Yes | Yes |
| Design & cooling | ||
| Weight | 2.2 kg | 2.4 kg |
| Thickness | 23 mm | 24.1 mm |
| Width | 354 mm | 358.8 mm |
| Depth | 251 mm | 262.4 mm |
| Body material | Aluminium, Plastic | Aluminium, Plastic |
| Colours | Black | Black, Gray |
| Cooling fans | 2 | 2 |
| Vapor chamber cooling | No | No |
| Liquid metal (CPU) | No | No |
| Ports & wireless | ||
| Thunderbolt / USB4 | Thunderbolt 4 | — |
| Thunderbolt or USB4 | Yes | No |
| USB-C ports | 2 | 2 |
| USB-A ports | 2 | 3 |
| HDMI | HDMI 2.0 | HDMI 2.1 |
| HDMI 2.1 | No | Yes |
| (Mini) DisplayPort | Yes | No |
| Ethernet port | Yes | Yes |
| SD card reader | No | No |
| 3.5 mm audio jack | Yes | Yes |
| Wi-Fi standard | Wi-Fi 6 | Wi-Fi 6 |
| Bluetooth | 5.2 | 5.2 |
| Keyboard & camera | ||
| Backlit keyboard | Yes | Yes |
| Numeric keypad | Yes | Yes |
| Key travel | 1.7 mm | 1.5 mm |
| Webcam | 720p | 720p |
| IR camera (face login) | No | No |
| Fingerprint reader | No | No |
| Audio | ||
| Speakers | 2 speakers | 2.0 |
| Dolby Atmos | Yes | No |
