vs
7.7Graphics6.4
7.6Overall performance7.2
8.8Display4.8
2.8Memory & storage7.4
3.3Battery & portability6.8
3.9Features & cooling3.4
Dimensions
Size comparison
Legion Pro 5 16 Gen 8 RTX 4070 (2023)Pulse 15 RTX 4060 (2023)
| Legion Pro 5 16 Gen 8 RTX 4070 (2023) | Pulse 15 RTX 4060 (2023) | Difference | |
|---|---|---|---|
| Depth | 260 mm | 259 mm | +1 mm |
| Width | 363 mm | 359 mm | +4 mm |
| Thickness | 27 mm | 26.9 mm | +0.1 mm |
| Weight | 2.6 kg | 2.3 kg | +0.3 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Legion Pro 5 16 Gen 8 RTX 4070 (2023) better than Pulse 15 RTX 4060 (2023)?
- Refresh rate240 Hz vs 144 Hz+67%
- Resolution classQHD (1440p/1600p) vs Full HD (1080p/1200p)
- GPU compute (FP32)21.8 TFLOPS vs 16 TFLOPS+36%
- Brightness500 nits vs 300 nits+67%
- 3DMark Steel Nomad Light13,240 vs 10,960+21%
- GPU shader cores4,608 vs 3,072+50%
- CPU cores14 vs 10+40%
- G-Sync / FreeSyncYes · Pulse 15 RTX 4060 (2023): No
- HDRYes · Pulse 15 RTX 4060 (2023): No
- RAM (base)16 GB vs 8 GB2×
- USB-C charging (Power Delivery)Yes · Pulse 15 RTX 4060 (2023): No
- USB-C ports2 vs 12×
Why is Pulse 15 RTX 4060 (2023) better than Legion Pro 5 16 Gen 8 RTX 4070 (2023)?
- RAM (up to)16 GB vs 64 GB4×
- SSD (up to)1,000 GB vs 2,048 GB2×
- Battery capacity80 Wh vs 90 Wh+12%
- Weight2.6 kg vs 2.3 kg+13%
- Max. supported RAM32 GB vs 64 GB2×
- Key travel1.5 mm vs 1.7 mm+13%
- Max CPU clock4.7 GHz vs 4.9 GHz+4%
Specifications
Side by side
| Graphics | ||
| Graphics card | GeForce RTX 4070 Laptop | GeForce RTX 4060 Laptop |
| GPU maker | NVIDIA | NVIDIA |
| GPU power (TGP) | 140 W | 140 W |
| Video memory | 8 GB | 8 GB |
| Video memory type | GDDR6 | GDDR6 |
| GPU shader cores | 4,608 | 3,072 |
| GPU compute (FP32) | 21.8 TFLOPS | 16 TFLOPS |
| 3DMark Steel Nomad Light | 13,240 | 10,960 |
| Processor | ||
| Processor | Core i9-13900HX | Core i7-13620H |
| CPU maker | Intel | Intel |
| CPU cores | 14 | 10 |
| CPU threads | — | 16 |
| Max CPU clock | 4.7 GHz | 4.9 GHz |
| Processor options | Core i7-13700HX, Core i9-13900HX | Core i7-13620H, Core i7-13700H, Core i9-13900H |
| Geekbench 6 multi-core | — | 12,798 |
| Geekbench 6 single-core | — | 2,586 |
| Cinebench 2024 multi-core | — | 843 |
| Display | ||
| Screen size | 16″ | 15.6″ |
| Resolution | 2560 × 1600 | 1920 × 1080 |
| Resolution class | QHD (1440p/1600p) | Full HD (1080p/1200p) |
| Refresh rate | 240 Hz | 144 Hz |
| Panel type | IPS | IPS |
| Brightness | 500 nits | 300 nits |
| sRGB coverage | 99% | 100% |
| Response time | 7 ms | — |
| DCI-P3 coverage | 71% | — |
| Pixel density | 189 ppi | 141 ppi |
| Aspect ratio | 16:10 | 16:9 |
| G-Sync / FreeSync | Yes | No |
| Advanced Optimus | No | No |
| MUX switch | Yes | Yes |
| HDR | Yes | No |
| Touchscreen | No | No |
| Memory & storage | ||
| RAM (up to) | 16 GB | 64 GB |
| RAM (base) | 16 GB | 8 GB |
| RAM type | DDR5 | DDR5 |
| RAM speed | 5,600 MHz | 5,200 MHz |
| Max. supported RAM | 32 GB | 64 GB |
| RAM slots | 2 | 2 |
| Upgradable RAM | Yes | Yes |
| SSD (up to) | 1,000 GB | 2,048 GB |
| SSD (base) | 1,000 GB | 512 GB |
| M.2 SSD slots | 2 | 2 |
| SSD interface | PCIe 4.0 x4 | PCIe 4.0 x4 |
| Battery & power | ||
| Battery capacity | 80 Wh | 90 Wh |
| Power adapter | 300 W | 240 W |
| USB-C charging (Power Delivery) | Yes | No |
| Design & cooling | ||
| Weight | 2.6 kg | 2.3 kg |
| Thickness | 27 mm | 26.9 mm |
| Width | 363 mm | 359 mm |
| Depth | 260 mm | 259 mm |
| Body material | Aluminium, Plastic | Plastic |
| Colours | Black | Black, Gray |
| Cooling fans | 2 | 2 |
| Vapor chamber cooling | No | No |
| Liquid metal (CPU) | No | No |
| Fan noise (max. load) | 54.7 dB | — |
| Ports & wireless | ||
| Thunderbolt / USB4 | USB4 | — |
| Thunderbolt or USB4 | No | No |
| USB-C ports | 2 | 1 |
| USB-A ports | 4 | 3 |
| HDMI | HDMI 2.1 | HDMI 2.1 |
| HDMI 2.1 | Yes | Yes |
| (Mini) DisplayPort | No | No |
| Ethernet port | Yes | Yes |
| SD card reader | No | No |
| 3.5 mm audio jack | Yes | Yes |
| Wi-Fi standard | Wi-Fi 6 | Wi-Fi 6 |
| Bluetooth | 5.1 | 5.2 |
| Keyboard & camera | ||
| Backlit keyboard | Yes | Yes |
| Numeric keypad | Yes | Yes |
| Key travel | 1.5 mm | 1.7 mm |
| Webcam | 1,080p | 720p |
| IR camera (face login) | No | No |
| Fingerprint reader | No | No |
| Audio | ||
| Speakers | 2 speakers | 2.0 |
| Dolby Atmos | No | No |
