vs
6.3Graphics6.8
6.2Overall performance6.7
3.5Display8.0
9.4Memory & storage4.6
6.4Battery & portability9.1
5.6Features & cooling6.3
Dimensions
Size comparison
TUF Gaming A17 FA707 RTX 4060 (2023)Legion 5 15 RTX 5060 (2025)
| TUF Gaming A17 FA707 RTX 4060 (2023) | Legion 5 15 RTX 5060 (2025) | Difference | |
|---|---|---|---|
| Depth | 264 mm | 255.3 mm | +8.7 mm |
| Width | 395 mm | 344.9 mm | +50.1 mm |
| Thickness | 25 mm | 21.5 mm | +3.5 mm |
| Weight | 2.6 kg | 2.2 kg | +0.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is TUF Gaming A17 FA707 RTX 4060 (2023) better than Legion 5 15 RTX 5060 (2025)?
- RAM (up to)96 GB vs 32 GB3×
- SSD (up to)8,000 GB vs 1,000 GB8×
- GPU power (TGP)140 W vs 115 W+22%
- MUX switchYes · Legion 5 15 RTX 5060 (2025): No
- Battery capacity90 Wh vs 80 Wh+12%
- G-Sync / FreeSyncYes · Legion 5 15 RTX 5060 (2025): No
- Dolby AtmosYes · Legion 5 15 RTX 5060 (2025): No
- Screen size17.3″ vs 15.1″+15%
- Key travel1.7 mm vs 1.6 mm+6%
Why is Legion 5 15 RTX 5060 (2025) better than TUF Gaming A17 FA707 RTX 4060 (2023)?
- Resolution classFull HD (1080p/1200p) vs QHD (1440p/1600p)
- Brightness250 nits vs 500 nits2×
- Weight2.6 kg vs 2.2 kg+18%
- GPU compute (FP32)16 TFLOPS vs 18.4 TFLOPS+15%
- Refresh rate144 Hz vs 165 Hz+15%
- 3DMark Steel Nomad Light10,820 vs 12,308+14%
- Max. supported RAM32 GB vs 64 GB2×
- Wi-Fi standardWi-Fi 6 vs Wi-Fi 7+17%
- Thickness25 mm vs 21.5 mm+16%
- GPU shader cores3,072 vs 3,328+8%
- sRGB coverage62% vs 100%+61%
- USB-A ports2 vs 3+50%
Specifications
Side by side
| Graphics | ||
| Graphics card | GeForce RTX 4060 Laptop | GeForce RTX 5060 Laptop |
| GPU maker | NVIDIA | NVIDIA |
| GPU power (TGP) | 140 W | 115 W |
| Video memory | 8 GB | 8 GB |
| Video memory type | GDDR6 | GDDR7 |
| GPU shader cores | 3,072 | 3,328 |
| GPU compute (FP32) | 16 TFLOPS | 18.4 TFLOPS |
| 3DMark Steel Nomad Light | 10,820 | 12,308 |
| Processor | ||
| Processor | Ryzen 7 7735HS | Core Ultra 7 255HX |
| CPU maker | AMD | Intel |
| CPU cores | 8 | 8 |
| CPU threads | 16 | — |
| Max CPU clock | 4.8 GHz | 5.1 GHz |
| Processor options | Ryzen 7 7735HS, Ryzen 9 7940HS | Core i7-13645HX, Ryzen 7 250, Ryzen 7 260, Ryzen AI 7 350, Core Ultra 7 251HX, Core Ultra 7 255HX |
| Geekbench 6 multi-core | 10,408 | — |
| Geekbench 6 single-core | 2,188 | — |
| Cinebench 2024 multi-core | 748 | — |
| Display | ||
| Screen size | 17.3″ | 15.1″ |
| Resolution | 1920 × 1080 | 2560 × 1600 |
| Resolution class | Full HD (1080p/1200p) | QHD (1440p/1600p) |
| Refresh rate | 144 Hz | 165 Hz |
| Panel type | IPS | IPS |
| Brightness | 250 nits | 500 nits |
| sRGB coverage | 62% | 100% |
| Response time | 7 ms | — |
| DCI-P3 coverage | 100% | — |
| Pixel density | 127 ppi | 150 ppi |
| Aspect ratio | 16:9 | 16:10 |
| G-Sync / FreeSync | Yes | No |
| Advanced Optimus | No | No |
| MUX switch | Yes | No |
| HDR | No | No |
| Touchscreen | No | No |
| Memory & storage | ||
| RAM (up to) | 96 GB | 32 GB |
| RAM (base) | 16 GB | 16 GB |
| RAM type | DDR5 | DDR5 |
| RAM speed | 4,800 MHz | 5,600 MHz |
| Max. supported RAM | 32 GB | 64 GB |
| RAM slots | 2 | 2 |
| Upgradable RAM | Yes | Yes |
| SSD (up to) | 8,000 GB | 1,000 GB |
| SSD (base) | 500 GB | 512 GB |
| M.2 SSD slots | 2 | 2 |
| SSD interface | PCIe 4.0 x4 | PCIe 4.0 x4 |
| Battery & power | ||
| Battery capacity | 90 Wh | 80 Wh |
| Power adapter | 240 W | 245 W |
| USB-C charging (Power Delivery) | Yes | Yes |
| USB-C charging power | — | 100 W |
| Design & cooling | ||
| Weight | 2.6 kg | 2.2 kg |
| Thickness | 25 mm | 21.5 mm |
| Width | 395 mm | 344.9 mm |
| Depth | 264 mm | 255.3 mm |
| Body material | Aluminium, Plastic | Aluminium, Plastic |
| Colours | Gray | Black |
| Cooling fans | 2 | 2 |
| Vapor chamber cooling | No | No |
| Liquid metal (CPU) | No | No |
| Fan noise (max. load) | 57.2 dB | 50.1 dB |
| Ports & wireless | ||
| Thunderbolt / USB4 | USB4 | Thunderbolt 4 |
| Thunderbolt or USB4 | Yes | Yes |
| USB-C ports | 2 | 2 |
| USB-A ports | 2 | 3 |
| HDMI | HDMI 2.1 | HDMI 2.1 |
| HDMI 2.1 | Yes | Yes |
| (Mini) DisplayPort | No | No |
| Ethernet port | Yes | Yes |
| SD card reader | No | No |
| 3.5 mm audio jack | Yes | Yes |
| Wi-Fi standard | Wi-Fi 6 | Wi-Fi 7 |
| Bluetooth | 5.2 | 5.4 |
| Keyboard & camera | ||
| Backlit keyboard | Yes | Yes |
| Numeric keypad | Yes | Yes |
| Key travel | 1.7 mm | 1.6 mm |
| Webcam | 720p | 720p |
| IR camera (face login) | No | No |
| Fingerprint reader | No | No |
| Audio | ||
| Speakers | 2 speakers | 2.0 |
| Dolby Atmos | Yes | No |
