vs
3.1Graphics8.0
3.4Overall performance4.8
5.2Display2.4
4.2Memory & storage4.4
9.1Battery & portability2.4
6.7Features & cooling3.4
Dimensions
Size comparison
x14 RTX 3060 (2022)Legion 5 Gen 7 AMD RTX 3070 Ti (2022)
| x14 RTX 3060 (2022) | Legion 5 Gen 7 AMD RTX 3070 Ti (2022) | Difference | |
|---|---|---|---|
| Depth | 262.7 mm | 262.3 mm | +0.4 mm |
| Width | 321.5 mm | 358.8 mm | −37.3 mm |
| Thickness | 14.5 mm | 20 mm | −5.5 mm |
| Weight | 1.8 kg | 2.4 kg | −0.6 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is x14 RTX 3060 (2022) better than Legion 5 Gen 7 AMD RTX 3070 Ti (2022)?
- Refresh rate144 Hz vs 60 Hz2.4×
- CPU cores12 vs 62×
- SSD (up to)2,048 GB vs 1,024 GB2×
- Thunderbolt or USB4Yes · Legion 5 Gen 7 AMD RTX 3070 Ti (2022): No
- Weight1.79 kg vs 2.4 kg+34%
- Thickness14.5 mm vs 20 mm+38%
- Geekbench 6 multi-core9,122 vs 8,855+3%
- Brightness400 nits vs 300 nits+33%
- Cinebench 2024 multi-core715 vs 574+25%
- HDRYes · Legion 5 Gen 7 AMD RTX 3070 Ti (2022): No
- RAM typeLPDDR5 vs DDR5
- SD card readerYes · Legion 5 Gen 7 AMD RTX 3070 Ti (2022): No
Why is Legion 5 Gen 7 AMD RTX 3070 Ti (2022) better than x14 RTX 3060 (2022)?
- GPU power (TGP)75 W vs 140 W+87%
- 3DMark Steel Nomad Light6,381 vs 11,878+86%
- GPU compute (FP32)10.7 TFLOPS vs 18.3 TFLOPS+71%
- GPU shader cores3,840 vs 5,632+47%
- USB-A ports1 vs 33×
- Video memory6 GB vs 8 GB+33%
- Upgradable RAMNo · x14 RTX 3060 (2022): Yes
- M.2 SSD slots1 vs 22×
- Webcam720p vs 1,080p+50%
- Key travel1.3 mm vs 1.5 mm+15%
- Screen size14″ vs 15.6″+11%
Specifications
Side by side
| Graphics | ||
| Graphics card | GeForce RTX 3060 Laptop | GeForce RTX 3070 Ti Laptop |
| GPU maker | NVIDIA | NVIDIA |
| GPU power (TGP) | 75 W | 140 W |
| Video memory | 6 GB | 8 GB |
| Video memory type | GDDR6 | GDDR6 |
| GPU shader cores | 3,840 | 5,632 |
| GPU compute (FP32) | 10.7 TFLOPS | 18.3 TFLOPS |
| 3DMark Steel Nomad Light | 6,381 | 11,878 |
| Processor | ||
| Processor | Core i5-12500H | Ryzen 5 6600H |
| CPU maker | Intel | AMD |
| CPU cores | 12 | 6 |
| CPU threads | 16 | 12 |
| Max CPU clock | 4.5 GHz | 4.5 GHz |
| Processor options | Core i5-12500H, Core i7-12700H, Core i9-12900H | Ryzen 5 6600H, Ryzen 7 6800H |
| Geekbench 6 multi-core | 9,122 | 8,855 |
| Geekbench 6 single-core | 2,101 | 1,997 |
| Cinebench 2024 multi-core | 715 | 574 |
| Display | ||
| Screen size | 14″ | 15.6″ |
| Resolution | 1920 × 1080 | 1920 × 1200 |
| Resolution class | Full HD (1080p/1200p) | Full HD (1080p/1200p) |
| Refresh rate | 144 Hz | 60 Hz |
| Panel type | IPS | IPS |
| Brightness | 400 nits | 300 nits |
| sRGB coverage | 100% | 100% |
| Response time | 7 ms | — |
| DCI-P3 coverage | 100% | — |
| Pixel density | 157 ppi | 145 ppi |
| Aspect ratio | 16:9 | 16:9 |
| G-Sync / FreeSync | Yes | Yes |
| Advanced Optimus | Yes | Yes |
| MUX switch | Yes | Yes |
| HDR | Yes | No |
| Touchscreen | No | No |
| Memory & storage | ||
| RAM (up to) | 32 GB | 32 GB |
| RAM (base) | 16 GB | 16 GB |
| RAM type | LPDDR5 | DDR5 |
| RAM speed | 5,200 MHz | 4,800 MHz |
| Max. supported RAM | — | 32 GB |
| RAM slots | — | 2 |
| Upgradable RAM | No | Yes |
| SSD (up to) | 2,048 GB | 1,024 GB |
| SSD (base) | 256 GB | 256 GB |
| M.2 SSD slots | 1 | 2 |
| SSD interface | PCIe 4.0 x4 | PCIe 4.0 x4 |
| Battery & power | ||
| Battery capacity | 80 Wh | 80 Wh |
| Power adapter | 130 W | 300 W |
| USB-C charging (Power Delivery) | Yes | Yes |
| Design & cooling | ||
| Weight | 1.79 kg | 2.4 kg |
| Thickness | 14.5 mm | 20 mm |
| Width | 321.5 mm | 358.8 mm |
| Depth | 262.7 mm | 262.3 mm |
| Body material | Aluminium | Aluminium, Plastic |
| Colours | White | Gray |
| Cooling fans | 2 | 2 |
| Vapor chamber cooling | No | No |
| Liquid metal (CPU) | No | No |
| Fan noise (max. load) | 53 dB | — |
| Ports & wireless | ||
| Thunderbolt / USB4 | Thunderbolt 4 | — |
| Thunderbolt or USB4 | Yes | No |
| USB-C ports | 3 | 3 |
| USB-A ports | 1 | 3 |
| HDMI | HDMI 2.1 | HDMI 2.1 |
| HDMI 2.1 | Yes | Yes |
| (Mini) DisplayPort | No | No |
| Ethernet port | No | Yes |
| SD card reader | Yes | No |
| 3.5 mm audio jack | Yes | Yes |
| Wi-Fi standard | Wi-Fi 6E | Wi-Fi 6E |
| Bluetooth | 5.2 | 5.2 |
| Keyboard & camera | ||
| Backlit keyboard | Yes | Yes |
| Numeric keypad | No | Yes |
| Key travel | 1.3 mm | 1.5 mm |
| Webcam | 720p | 1,080p |
| IR camera (face login) | Yes | No |
| Fingerprint reader | No | No |
| Audio | ||
| Speakers | 2.0 | 2.0 |
| Dolby Atmos | Yes | No |
